| Nominal Outside Diameter (Nominal Size) | Mean Outside Diameter | Class 2 0.4 MPa |
Class 3 0.6 MPa |
Class 4 0.8 MPa |
Class 5 1.0 MPa |
|||||
|---|---|---|---|---|---|---|---|---|---|---|
| Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | |
| 63 | 63.0 | 63.3 | 1.5 | 1.9 | 2.2 | 2.7 | 2.8 | 3.5 | 3.5 | 4.1 |
| 75 | 75.0 | 75.3 | 1.8 | 2.2 | 2.6 | 3.1 | 3.4 | 4.2 | 4.1 | 4.9 |
| 90 | 90.0 | 90.3 | 2.1 | 2.6 | 3.1 | 3.7 | 4.0 | 5.0 | 5.0 | 5.7 |
| 110 | 110.0 | 110.4 | 2.5 | 3.1 | 3.7 | 4.4 | 4.9 | 6.1 | 6.1 | 7.1 |
| 125 | 125.0 | 125.4 | 2.9 | 3.4 | 4.3 | 5.0 | 5.6 | 6.9 | 6.9 | 8.0 |
| 140 | 140.0 | 140.5 | 3.2 | 3.8 | 4.8 | 5.6 | 6.3 | 7.7 | 7.7 | 8.9 |
| 160 | 160.0 | 160.5 | 3.7 | 4.3 | 5.4 | 6.3 | 7.1 | 8.7 | 8.7 | 10.2 |
| 180 | 180.0 | 180.6 | 4.1 | 4.9 | 6.1 | 7.1 | 8.0 | 9.8 | 9.8 | 11.5 |
| 200 | 200.0 | 200.6 | 4.5 | 5.4 | 6.8 | 7.9 | 8.9 | 10.9 | 10.9 | 12.8 |
| 225 | 225.0 | 225.7 | 5.2 | 6.2 | 7.7 | 9.0 | 10.0 | 12.2 | 12.2 | 14.3 |
| 250 | 250.0 | 250.8 | 5.7 | 6.7 | 8.5 | 9.8 | 11.0 | 13.5 | 13.5 | 15.9 |
| 280 | 280.0 | 280.9 | 6.4 | 7.4 | 9.5 | 11.0 | 12.3 | 15.1 | 15.1 | 17.8 |
| 315 | 315.0 | 316.0 | 7.2 | 8.3 | 10.7 | 12.3 | 13.8 | 17.0 | 17.0 | 20.0 |
| 355 | 355.0 | 356.1 | 8.1 | 9.4 | 12.0 | 13.8 | 15.4 | 19.0 | 19.0 | 22.4 |
| 400 | 400.0 | 401.2 | 9.1 | 10.5 | 13.5 | 15.6 | 17.6 | 21.8 | 22.0 | 25.8 |
Hot
Ring Fit PVC Pipe
₹4,000.00
Standards:
- Size Range: 63 mm to 315 mm
- Working Pressure: Available in 4, 6, 8, 10, and 12.5 kg/cm² variants
- Standard Compliance: IS 4985:2021 certified
- End Connection: Designed with Rubber Ring Joint for secure and leak-proof installation
Description
Additional information
| Color | Magenta with brown colour designing , Brown with Yellow Designing , Orange with yellow designing , Yellow with black designing , orange with Hanuman ji face , Green with God face , Green tone , Blue tone , Canvasite Green |
|---|
Reviews (0)
Attachment
Shipping & Delivery
MAECENAS IACULIS
Vestibulum curae torquent diam diam commodo parturient penatibus nunc dui adipiscing convallis bulum parturient suspendisse parturient a.Parturient in parturient scelerisque nibh lectus quam a natoque adipiscing a vestibulum hendrerit et pharetra fames nunc natoque dui.
ADIPISCING CONVALLIS BULUM
- Vestibulum penatibus nunc dui adipiscing convallis bulum parturient suspendisse.
- Abitur parturient praesent lectus quam a natoque adipiscing a vestibulum hendre.
- Diam parturient dictumst parturient scelerisque nibh lectus.
Scelerisque adipiscing bibendum sem vestibulum et in a a a purus lectus faucibus lobortis tincidunt purus lectus nisl class eros.Condimentum a et ullamcorper dictumst mus et tristique elementum nam inceptos hac parturient scelerisque vestibulum amet elit ut volutpat.
Features & Benefits
- Manufactured with Advanced Farming Technology: It guarantees precise and reliable water distribution for a wide range of applications across different industries.
- Convenient Push-Fit Joints: Enables quick and easy installation, reducing labor costs.
- All-Weather Jointing: Allows installation anytime of the year, regardless of weather conditions.
- Easy Installation: Faster installation allows quick water pressure testing and commissioning.
- Expansion & Contraction Adaptability: Prevents stress on joints for long-term performance.
- Resistant Joints: Joints are resistant to soil movement due to earthquake effects.
- Durable Elastomeric Rings: Offers a long shelf life and secure sealing.
- Corrosion & Chemical Resistance: Withstands acidic and alkaline solutions, ensuring longevity.
- Lightweight Design: Facilitates easy handling, transport, and installation.
Applications
- Ideal for mainline and sub-main pipelines in drip irrigation systems.
- Ensures efficient water distribution for agricultural applications.
- Used in sewerage transmission and reclaimed water distribution.
- Suitable for lift irrigation and other water management systems.
- Provides durability and reliability for industrial applications as well.
Standards:
- Size Range: 63 mm to 315 mm
- Working Pressure: Available in 4, 6, 8, 10, and 12.5 kg/cm² variants
- Standard Compliance: IS 4985:2021 certified
End Connection: Designed with Rubber Ring Joint for secure and leak-proof installation
